Testování rozhodovací tabulky

Co je testování rozhodovací tabulky?

Decision table testing is a software testing technique used to test system behavior for different input combinations. It is a systematic approach in which the different input combinations and their corresponding system behavior (output) are captured in a tabular form. That is why it is also called a Příčina-účinek table, where causes and effects are recorded for better test coverage.

A Rozhodovací tabulka is a tabular representation of inputs versus rules, cases, or test conditions. It is a highly effective tool for both complex testování softwaru and requirements management. A decision table helps check all possible combinations of conditions, and testers can easily identify missing conditions. Conditions are indicated using True (T) and False (F) values.

Example 1: Decision Table for a Login Screen

Let us create a decision table for a login screen.

Rozhodovací základní tabulka pro přihlašovací obrazovku

The condition is simple: if the user provides the correct username and password, they are redirected to the homepage. If any input is wrong, an error message is displayed.

Podmínky Pravidlo 1 Pravidlo 2 Pravidlo 3 Pravidlo 4
uživatelské jméno (T/F) F T F T
Heslo (T/F) F F T T
Výstup (E/H) E E E H

Legenda:

  • T – Správné uživatelské jméno/heslo
  • F – Nesprávné uživatelské jméno/heslo
  • E – Zobrazí se chybová zpráva
  • H – Zobrazí se domovská obrazovka

Tlumočení:

  • případ 1 – Username and password both wrong. The user is shown an error message.
  • případ 2 – Username correct, password wrong. The user is shown an error message.
  • případ 3 – Username wrong, password correct. The user is shown an error message.
  • případ 4 – Username and password both correct. The user navigates to the homepage.

When converting this to a modelový případ, you can create two scenarios, because the three error cases all test the same rule.

  • Enter the correct username and correct password, then click Login — the user should navigate to the homepage.
  • Enter a wrong username and/or wrong password, then click Login — the user should see an error message.

Example 2: Decision Table for an Upload Screen

Now consider a dialog box that asks the user to upload a photo under certain conditions:

  1. Only the “.jpg” format is allowed.
  2. File size must be less than 32 KB.
  3. Resolution must be 137 × 177.

If any condition fails, the system throws a corresponding error message; if all conditions are met, the photo uploads successfully.

Decision Table for Upload Screen

The decision table for this case is shown below.

Podmínky případ 1 případ 2 případ 3 případ 4 případ 5 případ 6 případ 7 případ 8
Formát . Jpg . Jpg . Jpg . Jpg Ne .jpg Ne .jpg Ne .jpg Ne .jpg
Velikost < 32 KB < 32 KB ≥ 32 KB ≥ 32 KB < 32 KB < 32 KB ≥ 32 KB ≥ 32 KB
Rozlišení 137 × 177 Not 137×177 137 × 177 Not 137×177 137 × 177 Not 137×177 137 × 177 Not 137×177
Výstup Fotografie byla nahrána Nesoulad rozlišení Size mismatch Size & resolution mismatch Format mismatch Format & resolution mismatch Format & size mismatch Format, size & resolution mismatch

From this table, you can create eight test cases for complete coverage:

  1. .jpg, < 32 KB, 137×177 → photo uploads successfully.
  2. .jpg, < 32 KB, not 137×177 → resolution-mismatch error.
  3. .jpg, ≥ 32 KB, 137×177 → size-mismatch error.
  4. .jpg, ≥ 32 KB, not 137×177 → size and resolution mismatch error.
  5. Not .jpg, < 32 KB, 137×177 → format-mismatch error.
  6. Not .jpg, < 32 KB, not 137×177 → format and resolution mismatch error.
  7. Not .jpg, ≥ 32 KB, 137×177 → format and size mismatch error.
  8. Not .jpg, ≥ 32 KB, not 137×177 → format, size, and resolution mismatch error.

Why Decision Table Testing is Important

Decision table testing is important because it tests many combinations of conditions and provides strong coverage for complex business logic. When system behavior differs for each set of inputs, the technique gives good coverage in a simple, easy-to-read representation.

In softwarové inženýrství, boundary value analysis and equivalence partitioning are similar techniques, but they are most effective when the system shows the stejný behavior across a large set of inputs. When the behavior is odlišný for each input combination, those techniques cannot ensure good coverage — and decision table testing becomes the better option.

This table also serves as a reference for requirements and functionality development because it is easy to understand and covers all combinations. The significance grows as inputs increase: the number of possible combinations is 2^n, where n is the number of inputs. For n = 10, which is common in web forms, that is 1,024 combinations. You cannot test all of them, but you can select a rich subset using decision-based testing.

SOUVISEJÍCÍ ČLÁNKY

Výhody testování rozhodovacích tabulek

  • Works when system behavior differs across inputs, where equivalence partitioning and boundary value analysis fall short.
  • The representation is simple, so it is easily interpreted and useful for both development and business teams.
  • Helps build effective combinations and ensures better test coverage.
  • Any complex business condition can be turned into a decision table.
  • Can ensure 100% coverage when the number of input combinations is low.

Nevýhody testování rozhodovací tabulky

The main disadvantage is that as the number of inputs increases, the table becomes more complex and harder to manage.

Nejčastější dotazy

Decision table testing is a black-box technique that captures combinations of input conditions and their expected outputs in a table. It ensures systematic coverage of complex business rules.

It maps causes (input conditions) to effects (system outputs). Capturing both sides in one table makes the relationship explicit, which is why it is also known as a cause-effect table.

The number of rules equals 2^n, where n is the number of binary conditions. For example, 4 conditions produce 16 rules, and 10 conditions produce 1,024 possible combinations.

Boundary value analysis suits inputs where behavior is the same across a range. Decision tables suit cases where each input combination produces a different output, providing coverage the other techniques miss.

Use it when a feature has multiple input conditions that interact to produce different outputs, such as login validation, form uploads, or pricing and discount rules with several dependencies.

As the number of conditions grows, the table expands exponentially (2^n) and becomes hard to manage. Testers usually select a representative subset of rules rather than testing every combination.

AI tools read requirements and generate decision tables automatically, identify missing or redundant rules, and collapse equivalent rules. This reduces manual effort while improving combination coverage.

Yes. AI can convert each rule in a decision table into a concrete test case with inputs and expected results, then prioritize them by risk so high-impact combinations are tested first.
